HIWIN HGH65HA Linear Guideway HG Block Linear Guide Rail CNC

Name: HIWIN HGH65HA Linear Guideway HG Block Linear Guide Rail CNC
Brand: HIWIN
Price: 1 USD

Quality HIWIN HGH65HA Linear Guideway HG Block Linear Guide Rail CNC for sale

Brand Name : HIWIN

Model Number : HGH65HA

Certification : DE1924083895474

Place of Origin : CHINA TAIWAN

MOQ : 1

Price : 1-100 USD

Payment Terms : T/T,L/C,D/A,D/P,Western Union

Supply Ability : 100000 pcs / per month

Delivery Time : 1-7 work days

Packaging Details : Small or with carton box, Bulk order with Wooden box

Series : HG

Model Size(mm) : 65 mm

No. of Blocks per Rail : 1

Rail Mounting Type : R- Mounting From Top

Rail Length(mm) : Max 4000mm, Butt-joint available

Preload Class : Z0- Light Preload , ZA- Medium Preload, ZB-Heavy Preload

Material : SNCM220 Carbon Steel

Dust Protection : SS-standard

Y -Symmetrical (E1＝E2) First hole dimension : Y= Symmetrical （E1=E2)

Installation : Easy

Application : NC lathe, EDM, measuring equipment

Smoothness : Smooth
